| Place of Origin: | China |
|---|---|
| Brand Name: | ANGELS |
| Certification: | TUV CE, ISO13485, ISO9001 |
| Model Number: | Nobel Biocare Replace® |
| Minimum Order Quantity: | 10pcs |
| Price: | USD8~12/pcs (included screw, 10mm) |
| Packaging Details: | 1pcs/bag |
| Delivery Time: | 3~5 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500,000pcs/month |
| Material: | Ti 6AI-4V ELI (Grade 5) | Warranty: | 12 Months |
|---|---|---|---|
| After-sale Service: | Online Technical Support | Size: | 10mm, 14mm |
| Compatible: | NP 3.5mm/ RP 4.0mm/ WP 5.0mm / SW 6.0mm | Connection: | Engaging |
| Properties: | Implant Materials & Artificial Organs | Product Tolerance: | +-0.01mm |
| High Light: | 14mm Pre Mill Abutment,10mm Pre Mill Abutment,Biocare Replace Pre Milled Abutment |
||
Nobel Biocare Replace® Implant Internal Titanium Premill Blank 14mm Engaging
NP 3.5mm/ RP 4.3mm/ WP 5.0mm / SW 6.0mm
Material:
Ti 6AI-4V ELI (Supply from Germany)
Feature:
* Simply efficiency
* Precision machined up to ± 5µm
* Benefit from a faster and controlled turnaround time
* Different diameter available of 10mm, 14mm
Pre-milled Abutment Blanks, you can now produce titanium customised abutments with your milling equipment.
Boost your efficiency by using your milling machines and benefit from all major implant connections.
Approved by CE, ISO 9001, ISO 13485
* We also can provide another 3 type of premill as above picture shown. Welcome to further inquire. Thanks.
Points of NobelReplace™ Implant:
Fig. 15
Replace™ Select implants are offered in two body geometries, parallel (Fig.15, left) and tapered (Fig.15, right). Both geometries have a machined collar of 1.5mm and are surface treated below the collar, extending to the apical. A V shaped thread pattern is common to both body geometries with a diminishing thread depth toward the apical of the implant. The tapered version is machined without cutting flutes (Fig.16) at the apical portion while the parallel version is produced with cutting flutes (Fig.14). All four platform diameter tapered implants are available in four advertised lengths of 8, 10, 13 and 16mm. Although
Fig. 16
each tapered implant is actually 0.6mm longer than advertised. 3.5mm platform parallel wall geometry implants are produced in four (10, 11.5, 13, 15mm) lengths while 4.3 and 5.0mm platform diameter implants are offered in one additional length of 18mm. Although each parallel implant is actually 0.75mm shorter than advertised. There are no parallel wall 6.0mm platform diameter implants available.
