| Place of Origin: | China |
|---|---|
| Brand Name: | ANGELS |
| Certification: | TUV CE, ISO13485, ISO9001 |
| Model Number: | Zimmer Screw-Vent® |
| Minimum Order Quantity: | 10pcs |
| Price: | USD6-9 |
| Packaging Details: | 1pcs/bag |
| Delivery Time: | 3~5 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500,000pcs/month |
| Material: | Ti 6AI-4V ELI (Grade 5) | Warranty: | 12 Months |
|---|---|---|---|
| After-sale Service: | Online Technical Support | Compatible: | NP 3.5mm / RP 4.5mm / WP 5.7mm |
| Gingival: | 3mm/ 4mm/ 5mm/ 6mm/Customized | Properties: | Implant Materials & Artificial Organs |
| Product Tolerance: | +-0.01mm | Screwdriver: | Hex 1.27mm |
| High Light: | WP 5.7mm Implant Healing Abutment,Zimmer Screw Vent Healing Abutment,WP Implant Healing Abutment |
||
Zimmer Screw Vent WP 5.7mm Implant Healing Abutment
Zimmer Screw-Vent® Implant Titanium Healing Cap Abutment Compatible
NP 3.5mm / RP 4.5mm / WP 5.7mm
Material:
Ti 6AI-4V ELI (Supply from Germany)
Feature:
* Titanium interface abutment
* Precision machined up to ± 5µm
* Combination of high fatigue strength
* Superior level of biocompatibility
* Can production Custom Gingival Heights
|
|
HEALING ABUTMENT |
A |
C |
||
| 20.017/3 | NP | 3mm | 4,50 | 3,00 | |
| 20.017/4 | NP | 4mm | 4,50 | 4,00 | |
| 20.017/5 | NP | 5mm | 4,50 | 5,00 | |
| 20.018/3 | RP | 3mm | 4,90 | 3,00 | |
| 20.018/4 | RP | 4mm | 4,90 | 4,00 | |
| 20.018/5 | RP | 5mm | 4,90 | 5,00 | |
| 20.019/3 | WP | 3mm | 5,90 | 3,00 | |
| 20.019/4 | WP | 4mm | 5,90 | 4,00 | |
| 20.019/5 | WP | 5mm | 5,90 | 5,00 | |
Points of Zimmer Tapered Screw-Vent® (TSV), Screw-Vent® Healing Cap:
Fig. 1
Healing abutments are machined as single entity, combining the screw and healing abutment body in to a singular unit. Three possible abutment heights of 3, 5, and 7mm (Fig.1) in several emergence profiles (Fig.2) are offered. 3.5mm platform diameter healing abutments with zero and 5.5mm flare are produced in heights of 3 and 5mm while 4.5mm flare abutments are
Fig. 2
available in heights of 3, 5 and 7mm. 4.5mm platform diameter healing abutments with 5.5mm and 6.5mm flare are machined in heights of 3 and 5mm while 4.5mm (zero) flare abutments are offered in heights of 3, 5 and 7mm. 5.7mm platform healing abutments are executed in a single flare emergence of 6.5mm in heights of 3 and 5mm. The healing abutments may be serviced with a 0.050' hex driver.
