| Place of Origin: | China |
|---|---|
| Brand Name: | ANGELS |
| Certification: | TUV CE, ISO13485, ISO9001 |
| Model Number: | Dentsply XiVE® |
| Minimum Order Quantity: | 5pcs |
| Price: | USD10-14 (included screw) |
| Packaging Details: | 1pcs/bag |
| Delivery Time: | 3~5 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500,000pcs/month |
| Material: | Ti 6AI-4V ELI (Grade 5) | Warranty: | 12 Months |
|---|---|---|---|
| After-sale Service: | Online Technical Support | Connection: | Engaging |
| Compatible: | 3.0mm/ NP 3.4mm/ RP 3.8mm/ WP 4.5mm/ 5.5mm | Properties: | Implant Materials & Artificial Organs |
| Product Tolerance: | +-0.01mm | ||
| High Light: | Dentsply Xive Abutment,Titanium Grade 5 Abutment,Multi Unit Xive Abutment |
||
Multi Unit Titanium Grade 5 Dentsply Xive Abutment
Dentsply XiVE® Titanium Ti-Base Abutment Compatible
3.0mm/ NP 3.4mm/ RP 3.8mm/ WP 4.5mm/ 5.5mm
Material:
Ti 6AI-4V ELI (Supply from Germany)
Feature:
* Titanium interface abutment
* 1pc Screw Included
* Precision machined up to ± 5µm
* Combination of high fatigue strength
* Superior level of biocompatibility
* Exterior retentions for more cementation bonding
Specific design ensures a stable union, reinforcing the structure of zirconium in the areas of greatest stress, softening edges and ensuring the service life of the prosthesis.
Furthermore, the saving is also shown in the less time needed when working on the most sensitive part of the prosthesis, the adjustment with the implant.
Approved by CE, ISO 9001, ISO 13485
|
|
TI BASE |
A |
B |
C |
D |
||
| 15.038 | NP | Non-engaging | 3,40 | Circular | 0,30 | 4,50 | |
| 16.038 | NP | Engaging | 3,40 | Hex. 2,20 | 0,30 | 4,50 | |
| 15.039 | RP | Non-engaging | 3,80 | Circular | 0,30 | 4,50 | |
| 16.039 | RP | Engaging | 3,80 | Hex. 2,20 | 0,30 | 4,50 | |
| 15.040 | WP | Non-engaging | 4,50 | Circular | 0,30 | 4,90 | |
| 16.040 | WP | Engaging | 4,50 | Hex. 2,20 | 0,30 | 4,90 | |
Product Description
Dentsply XIVE® Titanium Ti Base Abutment are prefabricated, screw-retained intraoral abutments designed to be connected directly to an endosseous implant for retention of a cemented dental prosthesis. They may be used for single- and multiple-tooth restorations. Dentsply XIVE® Titanium Ti Base Abutment are precisely machined from titanium alloy and attached to the implant fixture with a titanium screw. For use in any region of the mouth, they contain a standard. Each abutment is specific to the restorative platform of the seated implant.
Accessories
Titanium screw.
Contraindications
The following conditions would contraindicate use of Inclusive Titanium Abutments: (a) wall thickness less than 0.5 mm; (b) gingival margin diameter less than 0.5 mm wider than the implant; (c) angle corrections of more than 30 degrees; (d) less than 0.5 mm margin height; (e) less than 4.0 mm abutment height.
Sterility
Dentsply XIVE® Titanium Abutments are packaged NON-STERILE. Prior to use in the oral environment, they should be cleaned, disinfected, and sterilized firstly.
